Technical Specifications:
• Electrical Specification
• Input 100~240V, 50/60Hz, 0.5A
• Output 12V (+7%, -3%) ---2A (± 2%)
• Protection: Surge protection, over temperature protection, over current, voltage load protection ESD: EN61000-4-2 ± 4kV Contact; ± 8kV Air Surge: EN61000-4-5”, Combination Wave: Common Mode ± 4KV (12 ohms), Differential Mode ± 2kV (2 ohms).
• Working Temperature -30?~+70?(-22?~+158?).
• Working Humidity <95% RH.
Physical Properties
• Weight 170g(0.33lb).
• Dimension(Lxwxh) 84mmx41mmx26mm.
• Installation Mode Plane installation.
• Color Black.
• Input Plug 2-pin Euro plug.
• Outgoing Cord AC wire: 50cm(19.69”), DC wire: 80cm(31.5”).
• DC Plug F5.5mmxF2.1mmx12mm(F0.22”xF0.08”x0.47”).
Safety Standards
• Certification CE, FCC, UL-VI.
• Electrical Specification
• Input 100~240V, 50/60Hz, 0.5A
• Output 12V (+7%, -3%) ---2A (± 2%)
• Protection: Surge protection, over temperature protection, over current, voltage load protection ESD: EN61000-4-2 ± 4kV Contact; ± 8kV Air Surge: EN61000-4-5”, Combination Wave: Common Mode ± 4KV (12 ohms), Differential Mode ± 2kV (2 ohms).
• Working Temperature -30?~+70?(-22?~+158?).
• Working Humidity <95% RH.
Physical Properties
• Weight 170g(0.33lb).
• Dimension(Lxwxh) 84mmx41mmx26mm.
• Installation Mode Plane installation.
• Color Black.
• Input Plug 2-pin Euro plug.
• Outgoing Cord AC wire: 50cm(19.69”), DC wire: 80cm(31.5”).
• DC Plug F5.5mmxF2.1mmx12mm(F0.22”xF0.08”x0.47”).
Safety Standards
• Certification CE, FCC, UL-VI.
